Tent Specifications
| Aluminum profile | 1. high pressed extruded aluminum alloy 6061-T6, stainless, lightweight, durable, 48X84X3mm for 3-10m tent |
| 2. 68x122x3mm, 88x166x3mm, 108x150x3mm,102x203x4mm for 10-20m tent |
| 3. 113x259x4mm, 120x300x5mm for 20-40m tent |
| 4. 120x350x6mm for 40-50m tent |
| Steel parts | hot-dipped galvanized steel |
| Top roof fabric | 850g/sqm double coated pvc, block-out, waterproof , flame retardant meet M2, B1, DIN4102 standard |
| Side panels(optional) | (1) 650g/sqm double coated pvc, translucent, waterproof, flame retardant meet M2, B1, DIN4102 standard, or; |
| (2) 950g/sqm transparent pvc fabric |
| (3) solid walls: glass panel, sandwich panels, ABS panels, color steel sheet |
| Allowed temperature | -20° to 70° environment |
| Max wind loading capacity | 120km/hour |
| Snow loading | 30kg/sqm |
Tent Measurement Chart
Tent Width:3m-50m
Tent Length no limited. Extended length of tent by 5m a bay, such as 15m,20m,25m,30m,35m,40m......
Customized size is available
| Product Code | Tent Span | Tent partition width | Eave height | Roof height | Angle of Roof | Aluminium profile size(mm) |
| SHB-6 | 6 | 3 | 2.6 | 3.7 | 20° | 84X48X3 |
| SHB-8 | 8 | 3 | 2.6 | 4 | 20° | 84X48X3 |
| SHB-9 | 9 | 3 | 2.6 | 4.3 | 20° | 84X48X3 |
| SHB-10 | 10 | 5 | 2.6 | 4.8 | 20° | 122X68X3 |
| SHB-12 | 12 | 5 | 3 | 5.2 | 20° | 122X68X3 |
| SHB-15 | 15 | 5 | 4 | 6.4 | 18° | 166X88X3 |
| SHB-18 | 18 | 5 | 4 | 6.9 | 18° | 203X112X4 |
| SHB-20 | 20 | 5 | 4 | 7.2 | 18° | 203X112X4 |
| SHB-25 | 25 | 5 | 4 | 8 | 18° | 203X112X4 |
| SHB-30 | 30 | 5 | 4 | 8.9 | 18° | 250X120X5 |
| SHB-35 | 35 | 5 | 4 | 9.8 | 18° | 300X120X5 |
| SHB-40 | 40 | 5 | 4 | 10.6 | 18° | 300X120X5 |
| SHB-45 | 45 | 5 | 4 | 11.4 | 18° | 300X120X5 |
| SHB-50 | 50 | 5 | 4 | 12.3 | 18° | 350X120X5 |
| SHB-55 | 55 | 5 | 4 | 13.2 | 18° | 400X120X5 |
| SHB-60 | 60 | 5 | 4 | 14.4 | 18° | 400X120X5 |
| SHB-60 | 60 | 5 | 6 | 16.4 | 18° | 400X120X5 |
Tent Frame Structure Designs
Tent 3D Designs
FAQ
Q: How can I place order?
After all details has been discussed and confirmed with us, we can start production from the date of payment deposit 30% received. After finished production, you can pay the balance payment, we will arrange shipment.
The payment terms is 30% depoit and 70% balance before shipment by T/T transfer.
Q: What's the production lead time?
Our production lead time is 7-30 days depends on the exact order.
Q: What about the shipment?
We provide CIF, FOB or EXW.
CIF: We arrange shipment from our factory to your sea port.
FOB: We arrange shipment from our factory to the sea port from our side.
EXW: We don’t arrange shipment and you will work the shipment with your shipping agent.
Q:Do you have certifications?
Yes, we have SGS certificates, Including low temperature bending resistance certification, Scarlett 650g anti-UV4-5 certified, UV-resistant and certified mold proofing antibacterial, flame retardant certification 650gsm-B1, 850gsm-M2 flame retardant certification.
Q: Can you print our logos on the tent?
Yes. Customized logos can be printed on the tent fabric according to your requirements.
Q: Is that factory price?
Yes. We assure you all prices are based on factory.
Q: Does your tent be able to installed repeatedly? What is the life span?
Our tents can be assembled and dismantled easily and repeatedly with small transportation size. The lifespan of aluminium framework can reach 20-30 years, and 10-20 years for PVC fabrics depending on different conditions of usage.
Q: What documents are available?
A full range documents including structural drawings, packing list, installation manual and relative certificates can be provided. Moreover, customs declaration is provided. We provide one-stop service for you.
For more questions please kindly contact me, thank you.
